CAT7 Lan Cable

Cat7 Lan Cable sSTP RoHs pvc jacket

Category: Lan Cable

CAT7 Lan Cable is a high-performance network cable designed to meet the demands of modern networking environments. It offers superior performance compared to its predecessors, such as CAT5e and CAT6, making it ideal for applications that require high-speed data transmission and minimal signal interference.CAT7 cables are designed with improved attenuation and crosstalk characteristics. They have lower signal loss and reduced crosstalk compared to CAT6 cables, which helps in maintaining signal integrity over longer distances. PRODUCT NAME CONDUCTOR JACKET INSULATION OD CONDUCTOR RESISTANCE AT 20°C(Ω/KM,≤) LENGTH AWG CONDCUTOR(mm) MATERIAL CAT7 SSTP 23AWG 1/0.57 OF-C PVC/LSZH HDPE 7.8 70.8 305m/Box Key Features: Frequency – 1000MHz Transmission Speed – 10GBASE-T Available Length – 305M (1000ft) Conductor – 23AWG (1/0.57) (America wire gauge), bare copper Cable Construction – Shielded Twisted Pair (SSTP), each pair individually shielded, and an overall foil shield Jacket – PVC or LSZH or PE Working Temperature : -20℃~+80℃ Install – Used indoor, in-wall and in the ceiling Applications : Computers, routers, VoIP phones, IP cameras, printers, gaming consoles, routers, ethernet extenders,

EXPLORE MORE

CAT7 Lan Cable SSTP Ethernet cable

Category: Lan CableMOQ: 1000 Pieces

CAT7 Lan Cable are widely used. Because the non-RJ Cat 7 Ethernet Cord wiring system uses double-shielded cables, it can meet the needs of those regions where shielded twisted-pair systems are the mainstay, such as some European and Asian markets. The Cat 7 Ethernet Cable dual-shielding solution is mainly used in environments with severe electromagnetic interference, such as some broadcasting stations. Radio etc. In addition, Cat 7 Network Card can also be used in environments that require extremely low electromagnetic radiation for safety purposes. In addition, broadband smart communities and commercial buildings are also potential markets. The capacity of a CAT7 Ethernet Cable can meet the requirements of all twisted-pair cabling systems, including the limitation of replacing coaxial and not loving the shared sheath, while enjoying high performance and low cost. CAT7 Lan Cable Product Information: PRODUCT NAME CONDUCTOR JACKET INSULATION OD CONDUCTOR RESISTANCE AT 20°C(Ω/KM,≤) LENGTH AWG CONDCUTOR(mm) MATERIAL CAT7 SSTP 23AWG 1/0.57 OF-C PVC/LSZH HDPE 7.8 70.8 305m/Box Key Features: 1. Frequency – 600 MHz2. Transmission Speed – 10 GB 3. Available Length – 305M ( 1000ft ) 4. Condc

EXPLORE MORE

Cat7 Lan Cable sSTP high speed network cable

Category: Lan CableMOQ: 1000 Pieces

CAT7 Lan Cable Max Length Price Reviews Lan Cable is 23 AWG with 4 pairs (8C). The overall aluminum (AL) foil shield helps eliminate cross-talk and prevents electromagnetic interference (EMI). Suitable for 1 Gigabit and 10-Gigabit Ethernet. Bandwidth tested up to 600 MHz. Supports PoE, PoE+, and PoE++ (IEEE 802.3af/at/bt) up to 60W and 300V DC. HASSLE FREE PACKAGING. 1000 feet (305 meters) of our lan cable product has been packaged on a tangle free, easy pull reel/spool so you don’t have to worry about getting behind on your next job. All CAT7 Ethernet Cable are backward compatible with CAT6 Ethernet Cable and CAT5E Lan Cable . CAT7 Lan Cable Product Information: PRODUCT NAME CONDUCTOR JACKET INSULATION OD CONDUCTOR RESISTANCE AT 20°C(Ω/KM,≤) LENGTH AWG CONDCUTOR(mm) MATERIAL CAT7 SSTP 23AWG 1/0.57 OF-C PVC/LSZH HDPE 7.8 70.8 305m/Box Key Features: 1. Frequency – 600 MHz 2. Transmission Speed – 10 GB 3. Available Length – 305M ( 1000ft ) 4. Condcutor- 23AWG (1/0.57) (America wire gague), bare copper 5. Cable Construction – Shielded 6. Jacket- PVC 7. Install – Used indoor, in-wall and in the ceiling Applications: Computers, routers, VoIP phones, IP cameras, printers, gaming consoles

EXPLORE MORE

High Speed Lan CAT7 Bulk Ethernet Cable

Category: Lan CableMOQ: 1000 Pieces

High Speed Lan CAT7 Bulk Ethernet Cable data transmission at speeds up to 10,000 Mbps (10 Gigabit per second) and bandwidth of up to 600 MHz, which supports high-speed data transfer for online gaming and video streaming. Braided Shielded Gold Plated Copper Cat7 Patch Cable provides data transmission at speeds up to 10,000 Mbps (10 Gigabit per second) and bandwidth of up to 600 MHz, which supports high-speed data transfer for online gaming and video streaming. CAT7 Lan Cable are backward compatible with CAT6A Ethernet Cable and CAT6 Ethernet Cable as well as CAT5E Ethernet Cable . CAT7 Lan Cable Product Information PRODUCT NAME CONDUCTOR JACKET INSULATION OD CONDUCTOR RESISTANCE AT 20°C(Ω/KM,≤) LENGTH AWG CONDCUTOR(mm) MATERIAL CAT7 SSTP 23AWG 1/0.57 OF-C PVC/LSZH HDPE 7.8 70.8 305m/Box Key Features: 1. Frequency – 600 MHz 2. Transmission Speed – 10 GB 3. Available Length – 305M ( 1000ft ) 4. Condcutor- 23AWG (1/0.57) (America wire gague), bare copper 5. Cable Construction – Shielded 6. Jacket- PVC 7. Install – Used indoor, in-wall and in the ceiling Applications: Computers, routers, VoIP phones, IP cameras, printers, gaming consoles, routers, ethernet extenders, switch boxes, PoE,

EXPLORE MORE

CAT7 Lan Cable high quality network cable

Category: Lan CableMOQ: 1000 Pieces

CAT7 Lan Cable For PS4 provides data transmission at speeds up to 10,000 Mbps (10 Gigabit per second) and bandwidth of up to 600 MHz, which supports high-speed data transfer for online gaming and video streaming. Cat7 Lan Cable support bandwidth up to 600MHz, connect to your LAN/WAN segments and networking gear at maximum speeds and surf the net, stream videos, music and other data at high speed. Except Cat7 Lan Ethernet Cable , our factory also supply CAT5E Lan Cable and CAT6 Lan Cable , more information, please feel free to contact us anytime. CAT7 Lan Cable Product Information: PRODUCT NAME CONDUCTOR JACKET INSULATION OD CONDUCTOR RESISTANCE AT 20°C(Ω/KM,≤) LENGTH AWG CONDCUTOR(mm) MATERIAL CAT7 SSTP 23AWG 1/0.57 OF-C PVC/LSZH HDPE 7.8 70.8 305m/Box Key Features: 1. Frequency – 600 MHz 2. Transmission Speed – 10 GB 3. Available Length – 305M ( 1000ft ) 4. Condcutor- 23AWG (1/0.57) (America wire gague), bare copper 5. Cable Construction – Shielded 6. Jacket- PVC 7. Install – Used indoor, in-wall and in the ceiling Applications: Computers, routers, VoIP phones, IP cameras, printers, gaming consoles, routers, ethernet extenders, switch boxes, PoE, devices, etc..
